SCPI Command
10-15
Return data: <NR1> 0: PASS, 1: FAIL
I/O Condition, in decimal format, bit definition as follows:
20mA
2mA
200uA
20uA
2uA
200nA
20nA
CORRection:NULL:RESult?
It queries measurement data of each LC Null range.
Set command format: CORRection:NULL:RESult?
Parameter: None
Return data: <NRf>,<NRf>,<NRf>,<NRf>,<NRf>,<NRf>,<NRf>, the unit: mA.
CALCulate Subsystem
CALCulate:LIMit:FORMat
It sets or queries basis parameter (IR/LC) for judging Pass/Fail.
Set command format: CALCulate:LIMit:FORMat {<NR1>|IR|LC}
Parameter: <NR1> 0: LC, 1: IR
Return data: <NR1> 0: LC, 1: IR
CALCulate:CLEar
It clears measured and compared judgment result.
Set command format: CALCulate:CLEar
Parameter: None
Return data: None
CALCulate:RESult?
It displays measured and compared judgment result.
Set command forma:CALCulate:RESult?
Parameter: None
Return data: <NR1> 0: No Result, 1: FAIL, 2: PASS
CALCulate:CONDition[:LCT]:LOWer:ENABle
It sets or queries enabled compare function (lower limit).
Set command format: CALCulate:CONDition[:LCT]:LOWe:ENABle
{<NR1>|ON|OFF}
Parameter: <NR1> 0: OFF, 1: ON
Return data: <NR1> 0: OFF, 1: ON
CALCulate:CONDition[:LCT]:LOWer:DATA
It sets or queries the lower limit of compare function.
Set command format: CALCulate:CONDition[:LCT]:LOWer:DATA {<NRf>}
Parameter: <NRF>, when IR mode the range is 1 ~ 1P(Ω) or
when LC mode the range is 1nA ~ 20mA
Return data: < NRF > The unit is in Ω when it is under IR mode and the unit is in mA
when it is under LC mode.
CALCulate:CONDition[:LCT]:UPPer:ENABle
It sets or queries enabled compare function (upper limit).
Set command format:
CALCulate:CONDition[:LCT]:UPPer:ENABle {<NR1>|ON| OFF}
Parameter: <NR1> 0: OFF, 1: ON
Return data: <NR1> 0: OFF, 1: ON
