Remote Operation
5-31
9. SYSTem:COMMunicate:CAN:BAUD
Description:
Sets the CAN baudrate
Syntax:
SYSTem:COMMunicate:CAN:BAUD <NRf+>
Parameter:
Parameter
Baudrate
Parameter
Baudrate
0
10k
7
200k
1
20k
8
250k
2
40k
9
400k
3
50k
10
500k
4
80k
11
800k
5
100k
12
1000k
6
125k
Example:
SYSTem:COMMunicate:CAN:BAUD 12
Query Syntax:
SYSTem:COMMunicate:CAN:BAUD?
Return Parameter:
<NR1>
Query Example:
SYSTem:COMMunicate:CAN:BAUD?
Return Example:
12
10. SYSTem:COMMunicate:CAN:ID
Description:
Sets the CAN ID.
Syntax:
SYSTem:COMMunicate:CAN:ID <NR1>
Parameter:
11bit: 0 to 2047, 29bit: 0 to 536870911
Example:
SYSTem:COMMunicate:CAN:ID 1024
Query Syntax:
SYSTem:COMMunicate:CAN:ID?
Return Parameter:
<NR1>
Query Example:
SYSTem:COMMunicate:CAN:ID?
Return Example:
1024
11. SYSTem:COMMunicate:CAN:MASK
Description:
Sets the CAN ID mask.
Syntax:
SYSTem:COMMunicate:CAN:MASK <NR1>
Parameter:
11bit: 0 to 2047, 29bit: 0 to 536870911
Example:
SYSTem:COMMunicate:CAN:MASK 256
Query Syntax:
SYSTem:COMMunicate:CAN:MASK?
Return Parameter:
<NR1>
Query Example:
SYSTem:COMMunicate:CAN:MASK?
Return Example:
256
12. SYSTem:COMMunicate:CAN:MODE
Description:
Sets the CAN 11 bit / 29 bit mode.
Syntax:
SYSTem:COMMunicate:CAN:MODE <NR1>
Parameter:
0: 11bit, 1: 29bit
Example:
SYSTem:COMMunicate:CAN:MODE 1
Query Syntax:
SYSTem:COMMunicate:CAN:MODE?
Return Parameter:
<NR1>
Query Example:
SYSTem:COMMunicate:CAN:MODE?
Return Example:
1
13. SYSTem:COMMunicate:CAN:PADding
Description:
Sets the CAN padding function.
Syntax:
SYSTem:COMMunicate:CAN:PADding <Arg>
Parameter:
<Arg>: ENABLE | DISABLE
Example:
SYSTem:COMMunicate:CAN:PADding ENABLE
Query Syntax:
SYSTem:COMMunicate:CAN:PADding?
