Chroma 62000D Series User Manual

Overview
1-11
System Fault indicator
(O/P)
TTL: Active Low
Safety interlock (I/P)
Time accuracy: <100ms
Remote inhibit (I/P)
TTL: Active Low
Series & Parallel
operation
Master / Slave control for Parallel: 10 units
Auto Sequencing (List
mode)
Number of program
10
Number of sequence
100
Dwell time Range
2ms – 15,000s
Trig. Source
Manual / Auto / External
Auto Sequencing (Step
mode)
Start voltage
0 to Full scale
End voltage
0 to Full scale
Run time
00.001Sec to 100hr
Trig. Source
Auto
Input Specification
AC input voltage
3phase, 3wire + ground
3Φ 200Vac - 220Vac ±
10%
3Φ 380Vac - 480Vac ±
10%
(Output=8kW@200-
220 Vac input,
Output=12kW@380-
480 Vac input)
w/o Neutral
3Φ 200Vac - 220Vac ± 10%
3Φ 380Vac - 480Vac ± 10%
(Output=12kW@200-220 Vac input,
Output=18kW@380-480 Vac input)
w/o Neutral
AC frequency range
47 – 63 Hz
Power factor
Source
PF>0.97 @220Vac
PF>0.97 @380Vac
PF>0.95 @480Vac
Regn
PF>0.97 @220Vac
PF>0.95 @380Vac
PF>0.92 @480Vac
General Specification
Maximum Remote
Sense Line Drop
Compensation
12
2% of full scale voltage per line(4% total)
Operating Temperature
Rage
0

C ~ +40

C
Storage Temperature
Rage
-25

C ~ +70

C
Dimension Size
(HxWxD)mm
133 x 428 x 730 mm / 5.23 x 16.85 x 28.74 inch
Weight (kg)
32kg / 70.5lbs
39kg / 86.0lbs
All specifications are subject to change without prior notice.
Note
1.
Minimum output voltage is <0.5% of rate voltage at zero output setting.
2.
Minimum output current is<0.2% of rate current at zero output setting when
measured with rated load resistance.
3.
For input voltage variation over the AC input voltage range with constant rated
load.
