Chroma 62000D Series User Manual

Programmable Bidirectional DC Power Supply 62000D Series
Operating and Programming Manual
2-8
Table 2-1 Suggested Cable Specification
Conductor Area
Sectional Area
mm
2
Safe
Current (A)
Diameter for
Anti-pulling
Standard
(mm)
Copper
Conductor
8.0
55
6.65
±
0.15
Table 2-2 lists the PVC (105°C) wire specification references when the ambient temperature
is 30°C.
Table 2-2 PVC (105°C) Cable Specification
Conductor Area
Sectional Area
mm
2
Safe Current (A)
Copper
Conductor
Aluminum
conductor
1.25
15
--
2.0
20
--
3.5
30
--
5.5
40
--
8.0
55
--
14
70
50
22
90
70
30
120
90
38
145
100
50
175
120
80
230
150
100
260
200
125
300
240
150
350
270
200
425
330
250
500
380
325
600
450
400
700
500
500
800
600
Table 2-3 Breaker Rating
Model
Breaker Rating(A)
62180D-100/600/1200/1800
50A max.
62120D-100/600/1200
35A max.
62060D-100/600
20A max
