Chroma 62000D Series User Manual

Programmable Bidirectional DC Power Supply 62000D Series
Operating and Programming Manual
2-12
(c) (d)
Figure 2-4 Assembly for 100V Output Models
(a) (b)
(c) (d)
Figure 2-5 Assembly for 600V/1200/1800V Output Models
1. To meet the safety requirement, the safety cover must be tightly
secured.
2. The diameter of the wire connected to load must be able to carry
the maximum current applied.
3. Be sure to select proper output wire that can withstand the voltage
based on the model.
For safety, do not exceed rated current (varies with 62000D series
models) for the output current.
CAUTION
WARNING
