Cisco CRS-1 - Carrier Routing System Router Getting Started Guide

7-6
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Chapter 7 RP Redundancy and Hardware Administration on Cisco IOS XR Software
Command Syntax for Hardware Nodes (location nodeID)
Figure 7-2 Display NodeID with the show platform Command
Note For each line card installed in the system, there are two entries in the show platform output. For CLI
commands, use the entry with the module “CPU0.” This entry also displays the Physical Line Interface
Module (PLIM) type. Example:
Node Type PLIM State Config State
-----------------------------------------------------------------------------
0/2/CPU0 MSC 16OC48-POS/DPT IOS-XR RUN PWR,NSHUT,MON
Examples of nodeID Command Syntax
The following examples of nodeID syntax are provided:
• NodeID for a Switch Fabric Module Command, page 7-6
• NodeID for an Install Command (to Identify a Line Card Module), page 7-7
NodeID for a Switch Fabric Module Command
The following command displays the connectivity information for a fabric card:
admin show controllers fabric connectivity location nodeID
Example:
RP/0/RPO/CPU:router# admin show controllers fabric connectivity location 0/SM0/SP
Card In Tx Planes Rx Planes Monitored Total Percent
R/S/M Use 01234567 01234567 For (s) Uptime (s) Uptime
-------------------------------------------------------------------------------
In this example, the command references the fabric card in rack “0,” slot “SM0,” with module “SP.”
116564
Node column displays
the nodeID for each card
The nodeID for
MSC cards
contains "CPU0"
RP/0/RP0/CPU0:router# show platform
Node Type PLIM State Config State
-------------------------------------------------------------------------------------------------------------------
0/1/SP MSC(SP) N/A IOS-XR RUN PWR,NSHUT,MON
0/1/CPU0 MSC 16OC48-POS/DPT IOS-XR RUN PWR,NSHUT,MON
0/2/SP MSC(SP) N/A IOS-XR RUN PWR,NSHUT,MON
0/2/CPU0 MSC 16OC48-POS/DPT IOS-XR RUN PWR,NSHUT,MON
0/3/SP MSC(SP) N/A IOS-XR RUN PWR,NSHUT,MON
0/3/CPU0 MSC 16OC48-POS/DPT IOS-XR RUN PWR,NSHUT,MON
0/RP0/CPU0 RP(Active) N/A IOS-XR RUN PWR,NSHUT,MON
0/RP1/CPU0 RP(Standby) N/A IOS-XR RUN PWR,NSHUT,MON
0/SM0/SP FC/S(SP) N/A IOS-XR RUN PWR,NSHUT,MON
0/SM1/SP FC/S(SP) N/A IOS-XR RUN PWR,NSHUT,MON
RP/0/RP0/CPU0:router#
