Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Chapter 2 Cisco IOS XR Basic Configuration Management
Navigating the Cisco IOS XR Command Modes
Figure 2-4 illustrates the basic command mode navigation for the CLI. Note that only a small sample of
the possible configuration submodes is shown.
Figure 2-4 Example of Command Mode Navigation in Cisco IOS XR software
Identifying the Command Mode in the CLI Prompt
The command mode is identified in the CLI prompt after the router name.
For example, when the router enters global configuration mode from the EXEC mode, the CLI prompt
changes to include “
(config)” after the router name:
RP/0/RP0/CPU0:routername# configure
RP/0/RP0/CPU0:routername(config)#
When the router enters interface configuration submode, the prompt changes to include “(config-if)”
after the router name:
RP/0/RP0/CPU0:routername(config)# interface POS 0/2/0/0
RP/0/RP0/CPU0:routername(config-if)#
116544
EXEC mode
Login
Interface
configuration submode
Configuration submode
examples
Router
configuration submode
Line template
configuration submode
Task group
configuration submode
Global configuration mode
Logical router configuration mode
(not available in current systems)
Admin configuration mode
Admin EXEC mode
