9-16
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 9 Configuring Interfaces
Configuring Ethernet Interfaces
• You cannot configure duplex mode on SFP module ports; they operate in full-duplex mode except
in these situations:
– When a Cisco1000BASE-T SFP module is in the SFP module slot, you can configure duplex
mode to auto or full. Half-duplex mode is supported with the auto setting.
– When a Cisco100BASE-FX SFP module is in the SFP module slot, you can configure duplex
mode to half or full. Although the auto keyword is available, it puts the interface in half-duplex
mode (the default for this SFP module) because the 100BASE-FX SFP module does not support
autonegotiation.
• If both ends of the line support autonegotiation, we highly recommend the default setting of auto
negotiation.
• If one interface supports autonegotiation and the other end does not, configure duplex and speed on
both interfaces; do not use the auto setting on the supported side.
• When STP is enabled and a port is reconfigured, the switch can take up to 30 seconds to check for
loops. The port LED is amber while STP reconfigures. On the Cisco ME switch, STP is supported
on NNIs by default and can be enabled on ENIs. UNIs do not support STP.
Caution Changing the interface speed and duplex mode configuration might shut down and re-enable the
interface during the reconfiguration.
Setting the Interface Speed and Duplex Parameters
Beginning in privileged EXEC mode, follow these steps to set the speed and duplex mode for a physical
interface.
Note On dual-purpose ports, changing the interface type by entering the media-type interface configuration
command removes the speed and duplex configurations. See the
“Configuring a Dual-Purpose Port”
section on page 9-18 for information about speed and duplex setting on these ports.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the physical interface to be configured, and enter interface
configuration mode.
Step 3
no shutdown Enable the port, if necessary. By default, UNIs and ENIs are disabled,
and NNIs are enabled.

Cisco ME 3400 Specifications

General

Category	Switch
Rack Mountable	Yes
Jumbo Frame Support	Yes
Authentication Method	RADIUS, TACACS+
RAM	128 MB
Flash Memory	32 MB
Power Device	Internal power supply
Model	ME 3400
Layer	Layer 2
MAC Address Table Size	8000 entries
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	VLAN support, IGMP snooping, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x
Memory	128 MB
Power Supply	AC 120/230 V (50/60 Hz)
Dimensions (H x W x D)	4.4 cm x 44.5 cm x 24.2 cm
Routing Protocol	Static routing
