Cisco ME 3400 User Manual

13-14
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 13 Configuring IEEE 802.1Q Tunneling and Layer 2 Protocol Tunneling
Configuring Layer 2 Protocol Tunneling
This example shows how to configure Layer 2 protocol tunneling for CDP, STP, and VTP and to verify
the configuration.
Switch(config)# interface gigatethernet0/1
Switch(config-if)# l2protocol-tunnel cdp
Switch(config-if)# l2protocol-tunnel stp
Switch(config-if)# l2protocol-tunnel vtp
Switch(config-if)# l2protocol-tunnel shutdown-threshold 1500
Switch(config-if)# l2protocol-tunnel drop-threshold 1000
Switch(config-if)# exit
Switch(config)# l2protocol-tunnel cos 7
Switch(config)# end
Switch# show l2protocol
COS for Encapsulated Packets: 7
Port Protocol Shutdown Drop Encapsulation Decapsulation Drop
Threshold Threshold Counter Counter Counter
------- -------- --------- --------- ------------- ------------- -------------
Gi 0/1 cdp 1500 1000 2288 2282 0
stp 1500 1000 116 13 0
vtp 1500 1000 3 67 0
pagp ---- ---- 0 0 0
lacp ---- ---- 0 0 0
udld ---- ---- 0 0 0
Configuring Layer 2 Tunneling for EtherChannels
To configure Layer 2 point-to-point tunneling to facilitate the creation of EtherChannels, you need to
configure both the SP edge switch and the customer switch.
Configuring the SP Edge Switch
Beginning in privileged EXEC mode, follow these steps to configure a SP edge switch for Layer 2
protocol tunneling for EtherChannels:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Enter interface configuration mode, and enter the interface to be configured
as a tunnel port. This should be the edge port in the SP network that
connects to the customer switch. Valid interfaces are physical interfaces.
Step 3
no shutdown Enable the port, if necessary. By default, UNIs and ENIs are disabled, and
NNIs are enabled.
Step 4
switchport mode dot1q-tunnel Configure the interface as an 802.1Q tunnel port.
Step 5
l2protocol-tunnel point-to-point
[pagp | lacp | udld]
(Optional) Enable point-to-point protocol tunneling for the desired
protocol. If no keyword is entered, tunneling is enabled for all three
protocols.
Caution To avoid a network failure, make sure that the network is a
point-to-point topology before you enable tunneling for PAgP,
LACP, or UDLD packets.

Cisco ME 3400 Specifications

General

Category	Switch
Rack Mountable	Yes
Jumbo Frame Support	Yes
Authentication Method	RADIUS, TACACS+
RAM	128 MB
Flash Memory	32 MB
Power Device	Internal power supply
Model	ME 3400
Layer	Layer 2
MAC Address Table Size	8000 entries
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	VLAN support, IGMP snooping, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x
Memory	128 MB
Power Supply	AC 120/230 V (50/60 Hz)
Dimensions (H x W x D)	4.4 cm x 44.5 cm x 24.2 cm
Routing Protocol	Static routing
