40-11
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 40 Configuring Enhanced Object Tracking
Configuring Enhanced Object Tracking Features
Beginning in privileged EXEC mode, follow these steps to configure a primary interface for DHCP:
Configuring a Cisco IP SLAs Monitoring Agent and Track Object
Beginning in privileged EXEC mode, follow these steps to configure network monitoring with Cisco IP
SLAs:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Select a primary or secondary interface and enter interface
configuration mode.
Step 3
description string Add a description to the interface.
Step 4
ip dhcp client route track number Configure the DCHP client to associate any added routes with the
specified track number. Valid numbers are from 1 to 500.
Step 5
ip address dhcp Acquire an IP address on an Ethernet interface from DHCP.
Step 6
exit Return to global configuration mode.
Step 1
configure terminal Enter global configuration mode.
Step 2
ip sla operation-number Begin configuring a Cisco IP SLAs operation and enter IP SLA
configuration mode.
Step 3
icmp-echo {destination-ip-address |
destination hostname [source- ipaddr
{ip-address | hostname source-interface
interface-id]
Configure a Cisco IP SLAs end-to-end ICMP echo response time
operation and enter IP SLAs ICMP echo configuration mode.
Step 4
timeout milliseconds Set the amount of time for which the operation waits for a response
from its request packet.
Step 5
frequency seconds Set the rate at which the operation is sent into the network.
Step 6
threshold milliseconds Set the rising threshold (hysteresis) that generates a reaction event
and stores history information for the operation.
Step 7
exit Exit IP SLAs ICMP echo configuration mode.
Step 8
ip sla schedule operation-number [life
{forever | seconds}] start-time time |
pending | now | after time] [ageout
seconds] [recurring]
Configure the scheduling parameters for a single IP SLAs operation.
Step 9{
track object-number rtr operation-number
{state | reachability}
Track the state of a Cisco IOS IP SLAs operation and enter tracking
configuration mode.
Step 10
end Return to privileged EXEC mode.
Step 11
show track object-number Display tracking information to verify the configuration.
Step 12
copy running-config startup-config (Optional) Save your entries in the configuration file.
