21-23
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 21 Configuring IGMP Snooping and MVR
Displaying MVR Information
Displaying MVR Information
You can display MVR information for the switch or for a specified interface. Beginning in privileged
EXEC mode, use the commands in
Table 21-6 to display MVR configuration:
Configuring IGMP Filtering and Throttling
In some environments, for example, metropolitan or multiple-dwelling unit (MDU) installations, you
might want to control the set of multicast groups to which a user on a switch port can belong. You can
control the distribution of multicast services, such as IP/TV, based on some type of subscription or
service plan. You might also want to limit the number of multicast groups to which a user on a switch
port can belong.
With the IGMP filtering feature, you can filter multicast joins on a per-port basis by configuring IP
multicast profiles and associating them with individual switch ports. An IGMP profile can contain one
or more multicast groups and specifies whether access to the group is permitted or denied. If an IGMP
profile denying access to a multicast group is applied to a switch port, the IGMP join report requesting
the stream of IP multicast traffic is dropped, and the port is not allowed to receive IP multicast traffic
from that group. If the filtering action permits access to the multicast group, the IGMP report from the
port is forwarded for normal processing. You can also set the maximum number of IGMP groups that a
Layer 2 interface can join.
Ta b l e 21-6 Commands for Displaying MVR Information
Command Purpose
show mvr Displays MVR status and values for the switch—whether MVR is enabled or disabled,
the multicast VLAN, the maximum (512) and current (0 through 512) number of
multicast groups, the query response time, and the MVR mode.
show mvr interface [interface-id]
[members [vlan vlan-id]]
Displays all MVR interfaces and their MVR configurations.
When a specific interface is entered, displays this information:
• Type—Receiver or Source
• Mode—Access or Trunk
• VLAN—The MVR VLAN for the source port and the receiver VLAN for the receiver
port
• Status—One of these:
–
Active means the port is part of a VLAN.
–
Up/Down means that the port is forwarding or nonforwarding.
–
Inactive means that the port is not part of any VLAN.
• Immediate Leave—Enabled or Disabled
If the members keyword is entered, displays all multicast group members on this port or,
if a VLAN identification is entered, all multicast group members on the VLAN. The
VLAN ID range is 1 to 1001 and 1006 to 4094.
show mvr members [ip-address] Displays all receiver and source ports that are members of any IP multicast group or the
specified IP multicast group IP address.
