29-18
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 29 Configuring SNMP
Configuring SNMP
Configuring MIB Data Collection and Transfer
This section includes basic configuration for MIB data collection. For more information, see the Periodic
MIB Data Collection and Transfer Mechanism feature module at this URL:
http://www.cisco.com/en/US/products/sw/iosswrel/ps1829/products_feature_guide09186a008014c77d.
html
Beginning in privileged EXEC mode, follow these steps to configure a bulk-statistics object list and
schema options:
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
snmp mib bulkstat object-list list-name Define an SNMP bulk-statistics object list, and enter bulk-statistics
object-list configuration mode.
Step 3
add {object-name | oid} Add a MIB object to the bulk-statistics object list.
• For object-name, enter the name of the MIB object to add to the
list. You can enter only object names from the Interfaces MIB
or the Cisco Committed Access Rate MIB.
• For oid, enter the Object ID of the MIB object to add to the list.
All the objects in an object-list must be in the same MIB index, but
the objects need not belong to the same MIB table. Repeat the
command until all objects to be monitored are added.
Step 4
exit Return to global configuration mode.
Step 5
snmp mib bulkstat schema schema-name Name the SNMP bulk statistics schema, and enter bulk-statistics
schema configuration mode.
Step 6
object-list list-name Specify the bulk-statistics object list to be included in this schema.
Specify only one object list per schema. If multiple object-list
commands are entered, the most recent command overwrites the
previous command.
