21-22
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 21 Configuring IGMP Snooping and MVR
Configuring MVR
Configuring MVR on Trunk Ports
Beginning in privileged EXEC mode, follow these steps to configure a trunk port as an MVR receiver
port:
This example shows how to configure a port as an MVR trunk receiver port, assign it to a VLAN,
configure the port to be a static member of a group, and verify the results.
Switch(config)# mvr
Switch(config)# interface fastethernet 0/10
Switch(config)# switchport mode trunk
Switch(config)# mvr type receiver
Switch(config)# mvr vlan 100 receiver vlan 201
Switch(config)# mvr vlan 100 group 239.1.1.1 receiver vlan 201
Switch(config)# end
Switch# show mvr interface
To return the interface to its default settings, use the no mvr [type | immediate | vlan
vlan-id | group] interface configuration command.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
mvr Enable MVR on the switch.
Step 3
interface interface-id Enter the Layer 2 port to configure and enter interface
configuration mode.
Step 4
switchport mode trunk Set trunking mode to TRUNK unconditionally.
Note When you are configuring a trunk port as an MVR
receiver port, we recommend that the source port is
configured as a network node interface (NNI) and the
MVR trunk receiver port is configured as a user node
interface (UNI) or enhanced network interface (ENI).
Step 5
mvr type receiver Specify that the trunk port is an MVR receiver port.
Step 6
mvr vlan source-vlan-id receiver vlan
receiver-vlan-id
Enable this trunk port to distribute MVR traffic coming from
the MVR VLAN to the VLAN on the trunk identified by the
receiver VLAN.
Step 7
mvr vlan vlan-id group ip-address receiver vlan-id (Optional) Configure the trunk port to be a static member of
the group on the receiver VLAN.
Step 8
end Return to privileged EXEC mode.
Step 9
show mvr
show mvr interface
show mvr members
Verify the configuration.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
