42-12
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 42 Configuring IP Multicast Routing
Configuring IP Multicast Routing
To disable multicasting, use the no ip multicast-routing distributed global configuration command. To
return to the default PIM version, use the no ip pim version interface configuration command. To
disable PIM on an interface, use the no ip pim interface configuration command.
Configuring PIM Stub Routing
The PIM Stub routing feature supports multicast routing between the distribution layer and the access
layer. It supports two types of PIM interfaces, uplink PIM interfaces, and PIM passive interfaces. A
routed interface configured with the PIM passive mode does not pass or forward PIM control traffic, it
only passes and forwards IGMP traffic.
PIM Stub Routing Configuration Guidelines
• Before configuring PIM stub routing, you must have IP multicast routing configured on both the stub
router and the central router. You must also have PIM mode (dense-mode, sparse-mode, or
dense-sparse-mode) configured on the uplink interface of the stub router.
• The PIM stub router does not route the transit traffic between the distribution routers. Unicast
(EIGRP) stub routing enforces this behavior. You must configure unicast stub routing to assist the
PIM stub router behavior. For more information, see the
“Configuring EIGRP Stub Routing” section
on page 35-40.
• Only directly connected multicast (IGMP) receivers and sources are allowed in the Layer 2 access
domains. The PIM protocol is not supported in access domains.
• The redundant PIM stub router topology is not supported.
Enabling PIM Stub Routing
Beginning in privileged EXEC mode, follow these steps to enable PIM stub routing on an interface. This
procedure is optional.
To disable PIM stub routing on an interface, use the no ip pim passive interface configuration command.
Step 8
show running-config Verify your entries.
Step 9
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface on which you want to enable PIM stub routing, and
enter interface configuration mode.
Step 3
ip pim passive Configure the PIM stub feature on the interface.
Step 4
end Return to privileged EXEC mode.
Step 5
show ip pim interface Display the PIM stub that is enabled on each interface.
Step 6
show running-config Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
