29-23

Cisco ME 3400 Ethernet Access Switch Software Configuration Guide

OL-9639-07

Chapter 29 Configuring SNMP

Displaying SNMP Status

Ta b l e 29-6 Commands for Displaying SNMP Information

Feature Default Setting

show snmp Displays SNMP statistics.

show snmp engineID [local | remote] Displays information on the local SNMP engine and all remote engines that have

been configured on the device.

show snmp group Displays information on each SNMP group on the network.

show snmp mib bulk transfer Displays transfer status of files generated by the Periodic MIB Data Collection and

Transfer Mechanism (bulk statistics feature).

show snmp pending Displays information on pending SNMP requests.

show snmp sessions Displays information on the current SNMP sessions.

show snmp user Displays information on each SNMP user name in the SNMP users table.
