41-23
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
OL-9639-07
Chapter 41 Configuring Ethernet OAM, CFM, and E-LMI
Setting Up and Configuring Ethernet OAM
Step 5
ethernet oam link-monitor frame {threshold {high
{high-frames | none} | low {low-frames}} | window
milliseconds}
(Optional) Configure high and low thresholds for error
frames that trigger an error-frame link event.
• Enter threshold high high-frames to set a high
threshold in number of frames. The range is 1 to
65535. You must enter a high threshold.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 0 to 65535. The
default is 1.
• Enter window milliseconds to set the a window and
period of time during which error frames are counted.
The range is 10 to 600 and represents the number of
milliseconds in a multiple of 100. The default is 100.
Step 6
ethernet oam link-monitor frame-period
{threshold {high {high-frames | none} | low
{low-frames}} | window frames}
(Optional) Configure high and low thresholds for the
error-frame period that triggers an error-frame-period link
event.
• Enter threshold high high-frames to set a high
threshold in number of frames. The range is 1 to
65535. You must enter a high threshold.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 0 to 65535. The
default is 1.
• Enter window frames to set the a polling window size
in number of frames. The range is 1 to 65535; each
value is a multiple of 10000 frames. The default is
1000.
Step 7
ethernet oam link-monitor frame-seconds
{threshold {high {high-seconds | none} | low
{low-seconds}} | window milliseconds}
(Optional) Configure frame-seconds high and low
thresholds for triggering an error-frame-seconds link event.
• Enter threshold high high-seconds to set a high
threshold in number of seconds. The range is 1 to 900.
You must enter a high threshold.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 1 to 900. The default
is 1.
• Enter window frames to set the a polling window size
in number of frames. The range is 100 to 9000; each
value is a multiple of 100 milliseconds. The default is
1000.
Command Purpose
