Chapter 7 Configuring the Switch Ports
Configuring the LRE Ports
7-28
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Assigning a Private Profile to an LRE Port
Private profiles are set on a per-port basis. You can assign the same private profile
or different private profiles to the LRE ports on the switch. The default active
private profile on all LRE ports is LRE-10.
The switch resets the ports with the updated profile settings.
Beginning in privileged EXEC mode, follow these steps to assign a private profile
to an LRE port:
Use the show controllers lre commands to display the LRE link statistics and
profile information on the LRE ports. For information about these commands,
refer to the Catalyst 2900 Series XL and Catalyst 3500 Series XL Command
Reference.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface LRE-interface Enter interface configuration mode, and enter the number
of the LRE port to be configured.
Step 3
lre profile profile_name Enter the private profile name: LRE-5, LRE-10, or
LRE-15.
The default profile is LRE-10.
Step 4
end Return to privileged EXEC mode.
Step 5
show controllers lre profile
mapping
Verify the change.
