2-29
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Chapter 2 Getting Started with CMS
Cluster View and Cluster Builder
Candidate, Member, and Link Pop-Up Menus
Table 2-17 describes the menu options available when you right-click a
candidate-switch icon in Cluster Builder.
Table 2-18 describes the menu options available when you right-click a
member-switch icon in Cluster Builder. For more information about configuring
cluster members, see Chapter 5, “Clustering Switches.”
Table 2-17 Cluster Builder Candidate Pop-up Menu
Menu Option Action
Device Web Page Displays the device-management page for the device.
Add to Cluster Adds the selected candidate or candidates to the cluster.
Table 2-18 Cluster Builder Member Pop-up Menu
Menu Option Action
Switch Manager Display the VSM Home page for the selected device.
Bandwidth Graph Display a graph that plots the total bandwidth used by
the switch. This feature is not available on
Catalyst 1900 or Catalyst 2820 switches.
Host Name Config Change the name of the switch. For more information,
see the “Host Names” section on page 5-10.
Remove from Cluster Remove the selected switch from the cluster.
Show or hide
Candidates
Toggle between displaying candidate switches and not
displaying them.
Clear State Return switches that were down but are now up to the
green (up) state. Switches that are yellow are down or
were previously down. Applicable only to yellow
member switches.
