Chapter 2 Getting Started with CMS
Cluster View and Cluster Builder
2-30
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Table 2-19 describes the menu options available when you right-click a link in
Cluster Builder. For more information about displaying link information, refer to
the online help.
Table 2-19 Cluster Builder Link Pop-up Menu
Menu Option Action
Link Graph Display the performance graph for the link. One end of the
link must be connected to a port on a cluster member that is a
Catalyst 2900 XL or Catalyst 3500 XL switch. Links
between any mix of Catalyst 1900 and Catalyst 2820
switches cannot be graphed.
Link Report Display information about the link between two members. If
one end of the link is a candidate, the report only displays
information about the member switch.
