7-21
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Chapter 7 Configuring the Switch Ports
Configuring Inline Power on the Catalyst 3524-PWR Ports
Configuring Inline Power on the Catalyst 3524-PWR
Ports
The Catalyst 3524-PWR XL can supply inline power to the Cisco 7960 IP Phone,
if necessary. The Cisco 7960 IP Phone can also be connected to an AC power
source and supply its own power to the voice circuit. When the Cisco 7960 IP
Phone supplies its own power, any Catalyst 2900 XL or Catalyst 3500 XL can
forward IP voice traffic to and from the phone.
The Catalyst 3524-PWR XL senses if it is connected to a Cisco 7960 IP Phone. If
there is no power on the circuit, the switch supplies the power. If there is power
on the circuit, the switch does not supply it.
You can configure the switch to never supply power to the Cisco 7960 IP Phone
and to disable the detection mechanism. See the “Configuring Voice Ports”
section on page 7-17 for the CLI commands that you use to supply inline power
to a Cisco 7960 IP Phone.
Beginning in privileged EXEC mode, follow these steps to configure a port to
never supply power to Cisco 7960 IP Phones.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface Enter interface configuration mode, and enter the port to be
configured.
Step 3
power inline never Permanently disable inline power on the port.
To enable inline power when a Cisco 7960 IP Phone is
detected, use the power inline auto command.
Step 4
end Return to privileged EXEC mode.
Step 5
show power inline interface
configured
Verify the change.
