Chapter 9 Troubleshooting
Determining Why a Switch Is Not Added to a Cluster
9-8
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Determining Why a Switch Is Not Added to a Cluster
If a switch does not become part of the cluster, you can learn why by selecting
Views > Toggle View from the menu bar in Cluster Builder. Cluster View displays
the cluster as a double-switch icon and shows connections to devices outside the
cluster (Figure 9-1). Right-click the device (yellow label), and select
Disqualification Code.
Figure 9-1 Cluster View
Right-click a device
with a yellow label to
display the device
pop-up menu,
and select
Disqualification
Code to display the
reason it could not
join the cluster.
54506
mcluster
