Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Chapter 2 Getting Started with CMS
Cluster Manager and VSM
Port Modes and LEDs
The port modes (Table 2-5) determine the type of information displayed through
the port LEDs. When you change port modes, the meaning of the port LED colors
also changes.
Note The bandwidth utilization mode (UTIL LED) is not displayed on the VSM or
Cluster Manager switch images. Select Monitoring > Bandwidth Graph to
display the total bandwidth in use by the switch. Refer to the switch hardware
installation guide for information about using the UTIL LED.
To select or change a mode, click Mode until the desired mode LED is green.
Table 2-4 Cisco RPS 300 LED on the Catalyst 2912 LRE, 2924-LRE, and 3524-PWR XL Switches
Color RPS Status
Black (off) RPS is off or is not installed.
Green RPS is connected and operational.
Blinking green RPS is backing up another switch in the stack.
Amber RPS is connected but not functioning. The following conditions could exist:
• The RPS could be in standby mode. To put the RPS in Active mode, press the
Standby/Active button on the RPS, and the LED should turn green. If it does
not, one of these other two conditions could exist.
• One of the RPS power supplies could be down. Contact Cisco Systems.
• The RPS fan could have failed. Contact Cisco Systems.
Blinking amber Internal power supply of the switch is down, and redundancy is lost. The switch is
operating on the RPS.
