Chapter 1 Overview
Network Configuration Examples
Figure 1-1 Example Configurations
Catalyst 2900 XL
and Catalyst 3500 XL
GigaStack cluster
1-Gbps HSRP
54568
Catalyst 3548 XL switch
Cost-Effective
Wiring Closet
High-Performance
Workgroup
Redundant Gigabit
Backbone
Catalyst 3508 XL or 4908G-L3 switch
Catalyst 2900 XL and
Catalyst 3500 XL cluster
Catalyst 4908G-L3 switchCatalyst 4908G-L3 switch
Catalyst 2900 XL and
Catalyst 3500 XL cluster
