Examples
The following sample output is from the show ipsla mpls lsp-monitor summary command. This output
shows a pending status when an MPLS LSP ping operation is waiting to receive the timeout response from
the LSP Verification (LSPV) process.
RP/0/0/CPU0:router# show ipsla mpls lsp-monitor summary 1
MonID Op/GrpID TargetAddress Status Latest Operation Time
1 100001 192.255.0.4/32 up 19:33:37.915 EST Mon Feb 28 2005
1 100002 192.255.0.5/32 down 19:33:47.915 EST Mon Feb 28 2005
1 100003 192.255.0.6/32 pending 19:33:35.915 EST Mon Feb 28 2005
The following sample output shows that a down status is displayed after a timeout response is received.
RP/0/0/CPU0:router# show ipsla mpls lsp-monitor summary 1
MonID Op/GrpID TargetAddress Status Latest Operation Time
1 100001 193.100.0.1/32 down 12:47:16.417 PST Tue Oct 23 2007
1 100002 193.100.0.2/32 partial 12:47:22.418 PST Tue Oct 23 2007
1 100003 193.100.0.3/32 partial 12:47:22.429 PST Tue Oct 23 2007
1 100004 193.100.0.4/32 down 12:47:16.429 PST Tue Oct 23 2007
1 100005 193.100.0.5/32 down 12:47:21.428 PST Tue Oct 23 2007
This table describes the significant fields shown in the display.
Table 20: show ipsla mpls lsp-monitor summary Field Descriptions
DescriptionField
Monitor identifier.MonID
Operation identifiers that have been created by this
MPLS LSP monitor instance.
Op/GrpID
IPv4 Forward Equivalence Class (FEC) to be used
by this operation.
TargetAddress
Status of the paths. Values can be as follows:
• up—Indicates that the latest operation cycle was
successful.
• down—Indicates that the latest operation cycle
was not successful.
• pending—Indicates that the latest operation
cycle is waiting for an LSP ping or trace
response.
Status
Time the latest operation cycle was issued.Latest Operation Time
The following sample output is from the show ipsla mpls lsp-monitor summary group command:
RP/0/0/CPU0:router# show ipsla mpls lsp-monitor summary 1 group 100001
Cisco IOS XR System Monitoring Command Reference for the Cisco XR 12000 Series Router, Release 4.1
OL-24735-01 231
IP Service Level Agreement Commands
show ipsla mpls lsp-monitor summary
