Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
– In the Settings window navigation pane, under Hardware, select Add Hardware.
– Select Network Adapter from the list of devices, and then click Add.
– Name the new virtual network as Primary Network 3.
*
Make sure the Enable spoofing of MAC addresses check box is selected.
*
Click OK to apply the changes.
14. Right-click the SD-WAN VPX virtual machine and select Connect.
15. In the file menu, click Action, and then click Start to start the virtual machine.
16. When an SD-WAN VPX virtual machine is started for the first time, it automatically starts
the Deployment Wizard. This wizard asks questions about the deployment mode. Select
Setup Using Web UI. On the next screen, enter the IP address, netmask, and gateway for
the apA interface, and click Finish.
17. Aer SD-WAN VPX has restarted, log on to the browser based UI ((user name: admin,
password: password) at the IP address that you assigned to apA, for example: https://
172.16.0.213
18. In the HyperV Manager window, go to Virtual Switch Manager, and configure interfaces
in the following order; management, LAN, and WAN.
19. Download the hyperv.tgz file and untar it.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 208

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
