COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 116 www.cobham.com/gaisler
GR740
11.3.1 AHB status register
Table 103.0x00 - AHBS - AHB Status register
11.3.2 AHB failing address register
Table 104.0x04 - AHBFAR - AHB Failing Address Register
31 22 21 14 13 12 11 10 9 8 7 6 3 2 0
CECNT UECNT DONE RES SEC SBC CE NE HWRITE HMASTER HSIZE
0 0 000000NR NR NR
rw rw r r rw rw rw rw r r r
31: 22 Global correctable error count (CECNT) - Global correctable error count
21: 14 Global uncorrectable error count (UECNT) - Global uncorrectable error count
13 Task Completed (DONE): Task completed.
This is a read-only copy of the DONE bit in the status register.
12 RESERVED
11 Scrubber error counter threshold exceeded (SEC) - Scrubber error counter threshold exceeded.
Asserted together with NE.
10 Scrubber block error counter threshold exceeded (SBC) - Scrubber block error counter threshold
exceeded. Asserted together with NE.
9 Correctable Error (CE) - Correctable Error. Set if the detected error was caused by a correctable error
and zero otherwise.
8 New Error (NE) - Deasserted at start-up and after reset. Asserted when an error is detected. Reset by
writing a zero to it.
7 AMBA write signal (HWRITE) - The HWRITE signal of the AHB transaction that caused the error.
6: 3 AMBA master signal (HMASTER) - The HMASTER signal of the AHB transaction that caused the
error.
2: 0 AMBA size signal (HSIZE) - The HSIZE signal of the AHB transaction that caused the error
31 0
AHB FAILING ADDRESS
NR
r
31: 0 AHB failing address (AHB FAILING ADDRESS) - The HADDR signal of the AHB transaction that
caused the error.
