26.3 Registers

The L4STAT unit is programmed through registers mapped into APB address space.

Table 436. L4STAT counter control register

APB address offset Register

0x00 Counter 0 value register

0x04 Counter 1 value register

0x08 Counter 2 value register

0x0C Counter 3 value register

0x10 Counter 4 value register

0x14 Counter 5 value register

0x18 Counter 6 value register

0x1C Counter 7 value register

0x20 Counter 8 value register

0x24 Counter 9 value register

0x28 Counter 10 value register

0x2C Counter 11 value register

0x30 Counter 12 value register

0x34 Counter 13 value register

0x38 Counter 14 value register

0x3C Counter 15 value register

0x40 - 0x7C Reserved

0x80 Counter 0 control register

0x84 Counter 1 control register

0x88 Counter 2 control register

0x8C Counter 3 control register

0x90 Counter 4 control register

0x94 Counter 5 control register

0x98 Counter 6 control register

0x9C Counter 7 control register

0xA0 Counter 8 control register

0xA4 Counter 9 control register

0xA8 Counter 10 control register

0xAC Counter 11 control register

0xB0 Counter 12 control register

0xB4 Counter 13 control register

0xB8 Counter 14 control register

0xBC Counter 15 control register

0xC0 - 0xFC Reserved

0x100 Counter 0 max/latch register

0x104 Counter 1 max/latch register

0x108 Counter 2 max/latch register

0x10C Counter 3 max/latch register

0x110 Counter 4 max/latch register

0x114 Counter 5 max/latch register

0x118 Counter 6 max/latch register
