GR740-UM-DS, Nov 2017, Version 1.7 481 www.cobham.com/gaisler
GR740
43 Silicon Revisions and Errata
43.1 Overview
Table 602 below lists all design changes and errata that are further described in section 43.2 and to
which device revision the description applies.
The silicon reversion present in a device can be determined by the product marking as described in
table 600 in section 42. The silicon revision can also be determined by software by checking the
GRLIB build ID or JTAG version for the design. The build ID is present in the word stored at address
0xFFFFFFF0. The format is bits 31:16 - device ID, bits 15:0 - build ID. The build ID is part of the
GRLIB plug&play information. More information about plug&play areas can be found in section 2.5.
Table 602.Changes and errata vs device revisions
No. Name / Description Device silicon revision
01
- GRLIB build ID 4152 4153
- JTAG version 0 1
1 LEON4 and Level-2 cache fault-tolerance Affected Not affected
2 LEON4 DBPM function error Affected Not affected
3 LEON4 data cache clock-gating after device reset Affected Not affected
4 LEON4 partial WRPSR Affected Not affected
5 Ethernet Debug Communication Link (EDCL) hang after AMBA
ERROR
Affected Not affected
6 Memory controller incompatibility in full width mode with UT8SD-
MQ64M48
Affected Not affected
7 Temperature sensor This issue depends on the
package version used.
8 LVDS driver ESD sensitivity at low voltage HBM Affected Not affected
9 LEON4 store operation malfunction with MMU TLB disabled Affected Not affected
10 LEON4 break on RETT instruction Affected Not affected
11 DSU4 instruction cache diagnostic burst access Affected Not affected
12 Interrupt controller monitor/boot interface change Register interface and func-
tionality change.
13 Ethernet mode selection register clocked by TXCLK Affected Not affected
14 GRETH_GBIT1 MDIO access starved by GRETH_GBIT0 EDCL
infinite retries.
Affected Not affected
15 General purpose I/O port interrupt flag register immediately cleared Affected Not affected
16 AHB status register multiple error logging Added functionality in revi-
sion 1. Backward compatible
change.
17 PCI DMA controller enable and retry behaviour Affected Not affected
18 Force PCI AMBA multiplexing when PCIMODE_ENABLE is LOW. Change in behaviour.
19 Weak pull-downs on TESTEN, DSU_EN, and JTAG_TRST. Not present Present
20 Additional fields in register for bootstrap signals. Added functionality in revi-
sion 1. Backward compatible
change.
21 LEON4 direct cache replacement policy implementation Affected Not affected
