COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 346 www.cobham.com/gaisler
GR740
26.3.1 Counter value registers
Table 437.0x00-0x3C - CVAL0-15 - Counter 0-15 value register
0x11C Counter 7 max/latch register
0x120
Counter 8 max/latch register
0x124 Counter 9 max/latch register
0x128 Counter 10 max/latch register
0x12C Counter 11 max/latch register
0x130 Counter 12 max/latch register
0x134 Counter 13 rmax/latch egister
0x138 Counter 14 rmax/latch egister
0x13C Counter 15 max/latch register
0x140 - 0x17C Reserved
0x180 Timestamp register
0x184 - 0x1FC Reserved
31 0
CVAL
NR
rw
31: 0 Counter value (CVAL) - This register holds the current value of the counter. If the core has been
implemented with support for keeping the maximum count (MC field of Counter control register is
‘1’) and the Counter control register field CD is ‘1’, then the value displayed by this register will be
the maximum counter value reached with the settings in the counter’s control register. Writing to this
register will write both to the counter and, if implemented, the hold register for the maximum
counter value.
Table 436. L4STAT counter control register
APB address offset Register
