Table 243. 0x1C - GRETH_GBIT EDCL IP register
31 0
EDCL IP ADDRESS
*
rw
31: 0 EDCL IP address. Reset value: 
GRETH GBIT 0: 0xC0A80010 (192.168.0.16).
GRETH GBIT 1: 0xC0A80020 (192.168.0.32)
The four lowest bits of the EDCL IP address might be taken from GPIO inputs, see section 3.1.
Table 244. 0x20 - GRETH_GBIT Hash table msb register
31 0
Hash table (64:32)
NR
rw
31: 0 Hash table msb. Bits 64 downto 32 of the hash table.
Table 245. 0x24 - GRETH_GBIT Hash table lsb register
31 0
Hash table (64:32)
NR
rw
31: 0 Hash table lsb. Bits 31downto 0 of the hash table.
Table 246. 0x28 - GRETH_GBIT EDCL MAC address MSB.
31 16 15 0
RESERVED Bit 47 downto 32 of the EDCL MAC Address
0x50C2
rw
31: 16 RESERVED
15: 0 The 2 most significant bytes of the EDCL MAC Address.
Table 247. 0x2C - GRETH_GBIT EDCL MAC address LSB.
31 0
Bit 31 downto 0 of the EDCL MAC Address
*
rw
31: 0 The 4 least significant bytes of the EDCL MAC Address. Reset value: 
GRETH GBIT 0: 0x0075A330.
GRETH GBIT 1: 0x0075A340
The four lowest bits of the EDCL IP address might be taken from GPIO inputs, see section 3.1.
