COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 261 www.cobham.com/gaisler
GR740
Table 333. 0xCC - BMRTSF - GR1553B BM RT Subaddress filter register
31 0
SUBADDRESS FILTER MASK
0xFFFFFFFF
rw
31 Enables logging of mode commands on subaddress 31
30 : 1 Each bit position set to ‘1’ enables logging of transfers with the corresponding RT subaddress
0 Enables logging of mode commands on subaddress 0
Table 334. 0xD0 - BMRTMC - GR1553B BM RT Mode code filter register
31 20 19 18 17 16
RESERVED STSB STS TLC
0x1fff 1 1 1
r rwrwrw
1514131211109876543210
TSW RRTB RRT ITFB ITF ISTB IST DBC TBW TVW TSB TS SDB SD SB S
1111111111111111
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Each bit set to ‘1’ enables logging of a mode code:
31: 19 RESERVED
18 Selected transmitter shutdown broadcast & override selected transmitter shutdown broadcast (STSB)
17 Selected transmitter shutdown & override selected transmitter shutdown (STS)
16 Transmit last command (TLC)
15 Transmit status word (TSW)
14 Reset remote terminal broadcast (RRTB)
13 Reset remote terminal (RRT)
12 Inhibit & override inhibit terminal flag bit broadcast (ITFB)
11 Inhibit & override inhibit terminal flag (ITF)
10 Initiate self test broadcast (ISTB)
9 Initiate self test (IST)
8 Dynamic bus control (DBC)
7 Transmit BIT word (TBW)
6 Transmit vector word (TVW)
5 Transmitter shutdown & override transmitter shutdown broadcast (TSB)
4 Transmitter shutdown & override transmitter shutdown (TS)
3 Synchronize with data word broadcast (SDB)
2 Synchronize with data word (SD)
1 Synchronize broadcast (SB)
0 Synchronize (S)
Table 335. 0xD4 -BMLBS - GR1553B BM Log buffer start
31 0
BM LOG BUFFER START
0x00000000
rw
31 : 0 Pointer to the lowest address of the BM log buffer (8-byte aligned)
Due to alignment, bits 2:0 are always 0.
