COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 381 www.cobham.com/gaisler
GR740
Table 503. 0xB0 - LE3 -Latency Elapsed Time 3
31 0
LE3
0
rw
31: 0 Latency Elapsed Time Value 3 (LE3) - Latency Value (96 to 127) written by initiator.(only for target)
Table 504. 0xB4 - LE4 -Latency Elapsed Time 4
31 24 23 0
LE4 RESERVED
00
rw r
31: 24 Latency Elapsed Time Value 4 (LE4) - Latency Value (128 to 135) written by initiator. (only for tar-
get)
23: 0 RESERVED
Table 505. 0x0C0 - IE - Interrupt Enable
31201918 1110987 6543210
- NCTCE - SETE EDIE3 EDIE2 EDIE1 EDIE0 DITE DIRE TTE TME TRE SE
00 0 0 0
r rw r rw rw
31: 20 RESERVED
19: Non consecutive SpaceWire Time-Code received Interrupt Enable (NCTCE)
Note: Only available in silicon revision 1.
18: 11 RESERVED
10 Set ET External Interrupt Enable (SETE)
Note: Only available in silicon revision 1.
9 External Datation Interrupt Enable 3 (EDIE3)
8 External Datation Interrupt Enable 2 (EDIE2)
7 External Datation Interrupt Enable 1 (EDIE1)
6 External Datation Interrupt Enable 0 (EDIE0)
5 Distributed Interrupt TransmittedInterrupt Enable (DITE)
4 Distributed interrupt Received Received Interrupt Enable(DIRE)
3 Time-Code Transmitted Interrupt Enable (TTE) - SpaceWire Time-Code Transmitted Interrupt
Enable (only for initiator)
2 Time Message transmit Interrupt Enable (TME) - (only for initiator)
1 Time-Code Received Interrupt Enable (TRE) - SpaceWire Time-Code Received Interrupt Enable
(only for target)
0 Sync Interrupt Enable (SE) (only for target)
