GR740-UM-DS, Nov 2017, Version 1.7 384 www.cobham.com/gaisler
GR740
Note:
Reserved register fields should be written as zeros and masked out on read.
The registers which are not mentioned either as only for initiator or target are used in both initiator
and target.
The Definition of External Datation 1 Mask, External Datation 2 Mask and External Datation 3 Mask
registers are exactly same as External Datation 0 Mask Register.
The Definition of External Datation 1 Time, External Datation 2 Time and External Datation 3 Time
registers are exactly same as External Datation 0 Time Registers (i.e. External Datation 0 Preamble
Field and External Datation 0 Elapsed Time 0,1,2,3,4).
Table 511.0x114 - ED0ET0 - External Datation 0 Elapsed Time 0
31 0
ED0ET0
0
r
31: 0 External Datation Elapsed Time 0 (ED0ET0) - Latched CCSDS Time Code value (0 to 31) of local
ET counter.
Table 512.0x118 - ED0ET1 - External Datation 0 Elapsed Time 1
31 0
ED0ET1
0
r
31: 0 External Datation Elapsed Time 1 (ED0ET1) - Latched CCSDS Time Code value (32 to 63) of local
ET counter.
Table 513.0x11C - ED0ET2 - External Datation 0 Elapsed Time 2
31 0
ED0ET2
0
r
31: 0 External Datation 0 Elapsed Time 2 (ED0ET2) - Latched CCSDS Time Code value (64 to 95) of
local ET counter.
Table 514.0x120 - ED0ET3 - External Datation 0 Elapsed Time 3
31 0
ED0ET3
0
r
31: 0 External Datation 0 Elapsed Time 3 (ED0ET3) - Latched CCSDS Time Code value (96 to 127) of
local ET counter.
Table 515. 0x124 - ED0ET4 - External Datation 0 Elapsed Time 4
31 24 23 0
ED0ET4 RESERVED
00
rr
31: 24 External Datation 0 Elapsed Time 4 (ED0ET4) - Latched CCSDS Time Code value (128 to 135) of
local ET counter.
23: 0 RESERVED
