C-8 Compaq AlphaServer ES40 Service Guide
Table C–1 DPR Address Layout (Continued)
Location Logical Written
(Hex) Indicator By Used For
1000:10FF 1000 RMC Copy of EEROM on MMB1 J8 DIMM 8
1100:11FF 1100 RMC Copy of EEROM on MMB2 J1 DIMM 1
1200:12FF 1200 RMC Copy of EEROM on MMB2 J2 DIMM 2
1300:13FF 1300 RMC Copy of EEROM on MMB2 J3 DIMM 3
1400:14FF 1400 RMC Copy of EEROM on MMB2 J4 DIMM 4
1500:15FF 1500 RMC Copy of EEROM on MMB2 J5 DIMM 5
1600:16FF 1600 RMC Copy of EEROM on MMB2 J6 DIMM 6
1700:17FF 1700 RMC Copy of EEROM on MMB2 J7 DIMM 7
1800:18FF 1800 RMC Copy of EEROM on MMB2 J8 DIMM 8
1900:19FF 1900 RMC Copy of EEROM on MMB3 J1 DIMM 1
1A00:1AFF 1A00 RMC Copy of EEROM on MMB3 J2 DIMM 2
1B00:1BFF 1B00 RMC Copy of EEROM on MMB3 J3 DIMM 3
1C00:1CFF 1C00 RMC Copy of EEROM on MMB3 J4 DIMM 4
1D00:1DFF 1D00 RMC Copy of EEROM on MMB3 J5 DIMM 5
1E00:1EFF 1E00 RMC Copy of EEROM on MMB3 J6 DIMM 6
1F00:1FFF 1F00 RMC Copy of EEROM on MMB3 J7 DIMM 7
2000:20FF 2000 RMC Copy of EEROM on MMB3 J8 DIMM 8
2100:21FF 2100 RMC Copy of EEROM from CPU0
2200:22FF 2200 RMC Copy of EEROM from CPU1
2300:23FF 2300 RMC Copy of EEROM from CPU2
2400:24FF 2400 RMC Copy of EEROM from CPU3
2500:25FF 2500 RMC Copy of MMB 0 J5 FRU EEROM
2600:26FF 2600 RMC Copy of MMB 1 J7 FRU EEROM
2700:27FF 2700 RMC Copy of MMB 2 J6 FRU EEROM
2800:28FF 2800 RMC Copy of MMB 3 J8 FRU EEROM
2900:29FF 2900 RMC Copy of EEROM on CPB (PCI backplane)
2A00:2AFF 2A00 RMC Copy of EEROM on CSB (motherboard)
2B00:2BFF 2B00 RMC Last EV6 Correctable Error—ASCII
character string that indicates correctable
error occurred, type, FRU, and so on. Backed
up in CSB (motherboard) EEROM. Written
by Compaq Analyze
