Compaq AlphaServer ES40 User Manual

DPR Address Layout C-9
Table C–1 DPR Address Layout (Continued)
Location Logical Written
(Hex) Indicator By Used For
2C00:2CFF 2C00 RMC Last Redundant Failure—ASCII
character string that indicates redundant
failure occurred, type, FRU, and so on.
Backed up in system CSB (motherboard)
EEROM. Written by Compaq Analyze
2D00:2DFF 2D00 RMC Last System Failure—ASCII character
string that indicates system failure
occurred, type, FRU, and so on. Backed
up in CSB (motherboard) EEROM.
Written by Compaq Analyze.
2E00:2FFF 2E00 RMC Uncorrectable machine logout frame (512
bytes)
3000:3008 SROM SROM Version (ASCII string)
3009:300B RMC Rev Level of RMC first byte is letter Rev
[x/t/v] second 2 bytes are major/minor.
This is the rev level of the RMC on-chip
code.
300C:300E RMC Rev Level of RMC first byte is letter Rev
[x/t/v] second 2 bytes are major/minor.
This is the rev level of the RMC flash
code.
300F:3010 300F RMC Revision Field of the DPR Structure
3011:30FF Unused Unused
3100:31FF RMC Copy of PS0 EEROM (first 256 bytes)
3200:32FF RMC Copy of PS1 EEROM (first 256 bytes)
3300:33FF RMC Copy of PS2 EEROM (first 256 bytes)
3400 SROM Size of Bcache in MB
3401 SROM Flash SROM is valid flag; 8 = valid,
0 = invalid
3402 SROM System’s errors determined by SROM
3403:340F SROM/SRM Reserved for future SROM/SRM
communication
3410:3417 SROM/SRM Jump to address for CPU0
