Compaq AlphaServer ES40 User Manual

Registers D-55
Table D–21 Bit Definition of Logout Frame Registers (Continued)
Register
Identification Bit Field Text Translation Description
SMIR
(Environ_QW_1)
<7>
<6>
<5>
<4>
<3>
<2>
<1>
<0>
Inverted Sys_Rst = System is being reset
Inverted PCI_Rst1 = PCI Bus #1 is in reset
Inverted PCI_Rst0 = PCI Bus #0 is in reset
Set = System temperature over 50 degrees C failure
unused
Set = Sys_DC_Notok failure detected
Inverted OCP_RMC_Halt = OCP or RMC halt detected
Set = System Power Supply failure detected
CPUIR
(Environ_QW_2)
<7>
<6>
<5>
<4>
<3>
<2>
<1>
<0>
Set = CPU3 regulator or configuration sequence fail
Set = CPU2 regulator or configuration sequence fail
Set = CPU1 regulator or configuration sequence fail
Set = CPU0 regulator or configuration sequence fail
Set = CPU3 regulator is enabled
Set = CPU2 regulator is enabled
Set = CPU1 regulator is enabled
Set = CPU0 regulator is enabled
PSIR
(Environ_QW_3)
<7>
<6>
<5>
<4>
<3>
<2>
<1>
<0>
Not Used
Set = Power Supply 2 failed and was enabled
Set = Power Supply 1 failed and was enabled
Set = Power Supply 0 failed and was enabled
Not Used
Set = Power Supply 2 is enabled
Set = Power Supply 1 is enabled
Set = Power Supply 0 is enabled
