D-56 Compaq AlphaServer ES40 Service Guide
Table D–21 Bit Definition of Logout Frame Registers (Continued)
Register
Identification Bit Field Text Translation Description
System_PS/Temp/
Fan_Fault_
LM78_ISR
(Environ_QW_4)
<0>
<1>
<2>
<3>
<4>
<5>
<6>
<7>
<8>
<9>
<10>
<15:11>
<16>
<17>
<18>
<19>
<20>
<21>
Set = PS +3.3V out of tolerance
Set = PS +5V out of tolerance
Set = PS +12V out of tolerance
Set = VTERM out of tolerance
Set = Temperature zone 0 (PCI Backplane slots 1-3 area) over
limit failure
Set = LM75 CPU0-3 Temperature over limit failure
Set = System Fan 1 failure
Set = System Fan 2 failure
Set = CTERM out of tolerance
Unused
Set = -12V out of tolerance
Unused
Set = CPU0_VCORE +2V out of tolerance
Set = CPU0_VIO +1.5V out of tolerance
Set = CPU1_VCORE +2V out of tolerance
Set = CPU1_VIO +1.5V out of tolerance
Set = Temperature zone 1 (PCI Backplane slots 7-10 area) over
limit failure
Unused
<22>
<23>
<31:24>
<32>
<33>
<34>
<35>
<36>
<37>
<38>
<39>
<41:40>
<42>
<43>
<44>
<45>
<46>
<47>
<63:48>
Set = System Fan 4 failure
Set = System Fan 5 failure
Unused
Set = CPU2_VCORE +2V out of tolerance
Set = CPU2_VIO +1.5V out of tolerance
Set = CPU3_VCORE +2V out of tolerance
Set = CPU3_VIO +1.5V out of tolerance
Set = Temperature zone 2 (PCI Backplane slots 4-6 area) over
limit failure
Unused
Set = System Fan 3 failure
Set = System Fan 6 failure
00(Bin) = Power supply 0; 01 (Bin) = power supply 1; 10 (Bin) =
power supply 2; 11(Bin) = Reserved that has caused the
<42:47> warning condition.
Set = Power supply 3.3V rail above high amperage warning
Set = Power supply 5.0V rail above high amperage warning
Set = Power supply 12V rail above high amperage warning
Set = Power supply high temperature warning
Set = Power supply AC input low limit warning
Set = Power supply AC input high limit warning
Unused
