CRS-300 1:10 Redundancy Switch MN/CRS300.IOM
Front Panel Operation Revision 19
6–11
CONFIG: OPTIONS ALARM-MASK AUDIO
AUDIO MASK: NONE SW-ALMS
MODEM-ALMS BOTH (ENTER)
Use the ◄ ► arrow to select from the choices shown, and then press [ENT].
For all unmasked Switch or modem alarms, you may select which alarm types should force
the Switch to react with an audible buzzer located behind the front panel. In addition, a
relay closure to ground activates on Pin 20 of the System Alarms connector so that you may
attach other indicators.
6.2.2.4 CONFIG: REMOTE
SELECT REMOTE CONTROL:
LOCAL REMOTE (PRESS ENT)
Use the ◄ ► arrow keys to select LOCAL or REMOTE, and then press [ENT].
6.2.2.4.1 CONFIG: REMOTE LOCAL
When you select LOCAL, the Switch disables remote control, although remote monitoring is
always possible.
6.2.2.4.2 CONFIG: REMOTE REMOTE
REMOTE CONTROL: BUADRATE
INTERFACE (PRESS ENTER)
Use the ◄ ► arrow keys to select BAUDRATE or INTERFACE, and then press [ENT].
CONFIG: REMOTE REMOTE BAUDRATE
REMOTE CONTROL: BUADRATE
INTERFACE (PRESS ENTER)
You may select the baud rate of the remote control bus, connected locally to the M&C
computer. Use the ◄ ► arrow keys to change the baud rate. Values of 300, 1200, 2400,
4800, 9600 and 19200 baud are possible. Press [ENT] when done.
This setting does not affect the internal communications between the
Switch and the modems.
