CRS-300 1:10 Redundancy Switch MN/CRS300.IOM
Switch Connectors and Pinouts Revision 19
3–13
3.2.2.9 10/100/1000 Gigabit Ethernet Connector, RJ-45F (CRS-316/336)
See Table 3-12 for the RJ-45F connector pinouts for the 10/100/1000 Gigabit Ethernet User Data
Interface (used for Ethernet Bridge Mode) connector – “J4” on the CRS-316 and CRS-336 TMIs.
Table 3-12. 10/100/1000 Gigabit Ethernet Connector Pinouts
Pin Pair
Pin
1
5
4
2
1
2
3
3
6
4
7
8
