1.5.2 Modem vs. Terrestrial User Data Interface Specifications
Modem
TMI
User Data Type
User Data Connector(s)
CDM-625A
CDM-625
CRS-316
EIA-422, V.35
(1) DB-25F
Single-port Ethernet Bridge Mode
(1) RJ45
CRS-325
ASI
(2) BNCs
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO)
(1) DB-15F
(2) BNCs
CRS-330
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO, DDO, IDI)
(1) DB-15F
(4) BNCs
CRS-336
HSSI
(1) HD-50F
Single-port Ethernet Bridge Mode
(1) RJ45
CRS-340
EIA-422, V.35, LVDS
(1) DB-25F
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO)
(1) DB-15F
(2) BNCs
CRS-365D
Quad E1 (1 to 4 Ports of E1)
(2) DB-9F
CDM-570L/AL
CDM-570/A
CRS-330
G.703 (Balanced/Unbalanced)
(1) DB-15F/ (2) BNC
CRS-340
EIA-422, V.35, EIA-232
(1) DB-25F
G.703 (Balanced/Unbalanced)
(1) DB-15F/ (2) BNC
SLM-5650A
SLM-5650
CRS-316
MIL-STD-188-114, EIA-530
(1) DB-25F
GigE
(1) RJ45
CRS-325
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO)
(1) DB-15F
(2) BNCs
CRS-336
HSSI
(1) HD-50F
Single-port Ethernet Bridge Mode
(1) RJ45
CDM-Qx/QxL
CRS-316
EIA-530, V.35, EIA-232
(1) DB-25F
CRS-325
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO)
(1) DB-15F
(2) BNCs
CRS-336
HSSI
(1) HD-50F
CRS-365
Quad E1 (1 to 4 Ports of E1)
(4) RJ45s
CDM-710G/710GL
CRS-325
G.703 Unbal
(2) BNCs
CRS-336
HSSI
(1) HD-50F
GigE (one port only)
(1) RJ45
CDM-710
CRS-325
ASI
(2) BNCs
CRS-336
HSSI
(1) HD-50F
GigE (one port only)
(1) RJ45
CDM-700
CRS-325
OC3 Copper
(2) BNCs
CRS-336
HSSI
(1) HD-50F
GigE (one port only)
(1) RJ45
CRS-345
Multi-Port Unbal G.703 (1-4 ports)
(8) BNCs
CDM-600/L
CRS-330
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO, DDO, IDI)
(1) DB-15F
(4) BNCs
CRS-340
EIA-422, V.35,EIA-232, LVDS
(1) DB-25F
G.703 Bal (DDI,IDO, DDO, IDI)
G.703 Unbal (DDI, IDO)
(1) DB-15F
(2) BNCs
CRS-370
HSSI (User)
(1)HD-50F
