CRS-300 1:10 Redundancy Switch MN/CRS300.IOM
Introduction Revision 19
1–9
1.3.3 Plug-in Module (Card) Assemblies
Chapter 3. SWITCH CONNECTORS AND PINOUTS
1.3.3.1 CRS-300 System Controller Card Assembly
Figure 1-5. CRS-230
System Controller
(AS/0377)
DB-9 Female DB-25 Male
DB-9 Male DB-25 Female
1.3.3.2 Power Supply Card Assemblies
Figure 1-6. CRS-240
AC Power Supply
(AS/0376)
Figure 1-7. CRS-250
DC Power Supply
(PL/10458-1)
