Comtech EF Data CRS-300 - Figure 2-2. Typical Rack Mounting Configuration

To Next Page

To Previous Page

CRS-300 1:10 Redundancy Switch MN/CRS300.IOM

Installation Revision 19

2–4

Figure 2-2. Typical Rack Mounting Configuration

Feature Description

1 Custom Rack Enclosure (side view)

2 Standard Rack Shelving

Rack Enclosure Threaded

Mounting Rail (typical)

4 Product Front Panel (typical)

User-supplied Screws

6 CRS-300 1:10 Redundancy Switch

7 Redundant Modem

8 1 to 10 Traffic Modems

9 CRS-280/L IF Switch (optional)

10 CRS-350 ESC Switch (optional)
