B-1
Appendix B. CABLE DRAWINGS
B.1 Overview
This appendix contains technical specification drawings for the cables used with the CRS-300 1:10 Redundancy Switch. These cables are
divided into three categories – User/Utility Cables (Sect. B.2), Control Cables (Sect. B.3), and Control/IF/Data Cables (Sect. B.4).
The European EMC Directive (EN55022, EN50082-1) requires that you use properly shielded cables for DATA I/O. These
cables must be double-shielded from end-to-end, ensuring a continuous ground shield.
The tables in Sections B.3 and B.4 cross-reference the modem-specific cabling figures featured in Chapter 4. CABLES AND
CONNECTIONS.
B.2 User / Utility Cables
App. B FIG CEFD P/N DESCRIPTION USED FOR (TRAFFIC TYPE) … USED WITH CRS-300
…
B-1 N/A DB-25M DB-37F EIA-530 EIA-422/-449 DCE Conversion User data
B-2 N/A DB-25M 34-pin Winchester (Female) EIA-530 V.35 DCE Conversion User data
B-3 N/A DB-9M DB-9F CRS-300 Remote PC Serial Port User EIA-232 M&C / Firmware Update
