CRS-300 1:10 Redundancy Switch MN/CRS300.IOM
Cables and Connections Revision 19
4–2
When you connect your cabling, in most cases the modem accepts the male end of the cable,
while connectors on the Switch RMI or TMI plug-in card accept the female end of the cable in
the section of the module labeled “Modem Interface.”
See the subsections in Sect. 1.4 Description of CRS-300 Features for detailed
information on these interfaces.
The figures throughout this chapter provide cabling configuration examples for Switch
RMI or TMI interfaces – i.e., the interconnection of a Redundant Modem to a Switch
RMI module, or the interconnection between a Switch TMI module and a Traffic
Modem.
See these chapter sections for step-by-step instructions to connect a variety of Switch
and modem configurations:
• Sect. 4.2 Switch-to-Switch Connections
• Sect. 4.3 IF Cable Connections
• Sect. 4.4 CDM-625/A Modem Connections
• Sect. 4.5 CDM-570/A, CDM-570L/AL Modem Connections
• Sect. 4.6 SLM-5650/5650A Modem Connections
• Sect. 4.7 CDM-Qx/QxL Modem Connections
• Sect. 4.8 CDM-710G/710GL Modem Connections
• Sect. 4.9 CDM-710 Modem Connections
• Sect. 4.10 CDM-700 Modem Connections
• Sect. 4.11 CDM-600/L Modem Connections
