Connexity M6504 - Figure 83: IP Subscribers Status - Display Non-Connected Applicative Sessions; Figure 84: IP Subscribers Status - Display Connected Applicative Sessions

.
Page 114 15/09/2004 PS8149KENAA01
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
Example 1:
SUBSCRIBERS ........NOT CONNECT. STATUS
DN TYPE SESSION CAC
COMPLEMENTARY INFORMATIONS
----------------------------------------------
23 TDPC UNCONNECT. 01-0
57 ETHERSET UNCONNECT. 01-1
----------------------------------------------
Lines of complementary information:
L1: Site Cluster CLX board no.
L2: IP address Port RTP Location nb
Begin More
Figure 83: IP subscribers status - display non-connected applicative sessions
Example 2:
SUBSCRIBERS ........CONNECT. STATUS
DN MODEL SESSION CAC
COMPLEMENTARY INFORMATIONS
-------------------------------------------------
22 7808 CONNECT. 01-2
001-SITE LOC 02 (0-00)
131.129.11.124 : 40000
24 ETHERSET CONNECT. ........
003-SITE 3 02 (01)
131.129.13.62 : 40000
-------------------------------------------------
Lines of complementary information:
L1: Site Cluster CLX board no.
L2: IP address Port RTP Location nb
Begin More
Figure 84: IP subscribers status - display connected applicative sessions
DN
Shows the directory number of the IP sets matching the search criteria.
Note: For a multi-line subscriber, only the main directory number is displayed.
MODEL
Shows the type of IP set. For an IP DS set, gives the model of the set connected.
SESSION
Shows the status of the set's applicative session.
