3.9 INTEGR. BUFFER MANAGEMENT (MENU 3-9)
 For the Call Manager (F5): this menu is not available.
INTEGR. BUFFER MANAGEMENT
1 PARAMETER MANAGEMENT
2 RESET FLASH
ENTER YOUR CHOICE .
--------------------------------------------------
Figure 48: Menu 3-9 (Integrated buffer management)
3.9.1 PARAMETER MANAGEMENT (MENU 3-9-1)
 For the Call Manager (F5): this menu is not available.
PARAMETER MANAGEMENT
FUNCTIONAL STATUS
STAT: OPERATIONAL mode SUSPENDED
MODE: NORMAL FALLBACK (Fold)
TOTAL MEMORY CAPACITY 6 MB
SIZE REQUIRED FOR BACKUP 2 MB
MUFACT CALL NUMBER ……
MUFACT CALL PROFILE .
START/END MARKER
Figure 49: Integr. buffer parameter management (1)
PARAMETER MANAGEMENT
STORAGE BLOCKS OF RECORD TYPES
- TELEPHONY TYPE BLOCK 0
- PACKET DATA TYPE BLOCK 1
- CIRCUIT DATA TYPE BLOCK 2
- SERVICE TYPE (AND ALARMS) BLOCK 3
- SUPERVISION TYPE BLOCK 4
- MONITORING TYPE BLOCK 5
BLOCK n CHARACTERISTICS
- TOTAL SIZE (KB) 6 MB
- FALLBACK MODE SIZE (KB) 2 MB
- FILLING RATE (%) 50
- MANAGEMENT MODE .
- SATURATION THRESHOLD(%) 75
DELETE ALL RECORDS YES
Figure 50: Integr. buffer parameter management (2)
These screens are used to configure the integrated buffer and in particular the different file
blocks it contains.
