Connexity M6504 - Figure 55: Administration Parameters (Continued)

.
PS8149KENAA01 15/09/2004 Page 85
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
PRINT HEADER
ZZ • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 40 characters
PRINT FOOTER
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 40 characters
These fields are used to customise records on the printer for output in «format 4500».
The same fields can also be used in the case of an OXAL charge meter to note the ZZ
synchronisation characters (only «format 4500» and step by step: «PRINTER» are visible).
The printed record is in the following form:
BEACH HOTEL
10:30 11/07/98 FROM 19:30 08/07
PHONE 20 COST 25.50
COST (EURO) 3.92
THANKS FOR YOUR VISIT PLEASE CALL AGAIN
The field displaying the cost in Euros is not featured if the Euro value is not assigned.
SITE NUMBER OVERRIDDEN IN RECORD
The site number overridden by the record.
ADMINISTRATION PARAMETERS
--------- CALL RECORDS --------
STEP BY STEP OUTPUT YES
OUTPUT FORMAT EXTENDED FORMAT V1
TRUNK IDENTIFIED BY CARD/CHANNEL
TRUNCATE LAST 4 DIGITS YES
CALL TYPE INCOMING AND OUTGOING
DELETE RECORDS W/OUT CHARGING NO
--------- DATA RECORDS -----------
OUTPUT PACKET DATA NO
OUTPUT CIRCUIT DATA NO
----------------------------------------
Figure 55: Administration parameters (continued)
