Connexity M6504 - Signalling Management (Menu 5-6); Signalling Activation (Menu 5.6.1); Figure 191: Menu 5-6 (Signalling Management); Figure 192: Signalling Activation

.
PS8149KENAA01 15/09/2004 Page 205
Ce document est la propriété de EADS et ne doit pas être reproduit ou communiqué sans autorisation.
This document is the property of EADS and may not be copied or circulated without authorisation.
5.6 SIGNALLING MANAGEMENT (MENU 5-6)
 For the Call Manager (F5): this menu is not available.
SIGNALlING MANAGEMENT
1 SIGNALING ACTIVATION
2 NON ISDN SIGNALING PARAMETERS
3 ISDN SIGNALING PARAMETERS
4 INITIALIZE A SIGNALING TYPE
5 RECORDING PARAMETERS
6 IP SIGNALING PARAMETERS
ENTER YOUR CHOICE .
----------------------------------------
Figure 191: Menu 5-6 (Signalling management)
5.6.1 SIGNALLING ACTIVATION (MENU 5.6.1)
 For the Call Manager (F5): this menu is not available.
This MMC is used to activate only the signalling used for each type of trunk card present in
the system.
SIGNALLING ACTIVATION
FOR THE PHYSICAL TYPE DIGITAL TRE
Figure 192: Signalling activation
FOR THE PHYSICAL TYPE (FIX FORMAT BELOW)
DIGITAL TRK ANALOG TRK TIE LINE ISDN:T0 ISDN:T2 VOICE
IP
Select a trunk type.
Note: Digital TRK, TIE-LINE and ISDN T2 are available on M6501L/R / M6540 IP PBXs
and XL / XS /XC.
