5.5.1.1 SELECTION OF A TONE
Figure 161: Normal dial tone
SIGNAL TYPE
TONE ANNOUNCE
MENT
ANNOUNCEMENT OR
TONE
MULTISITE
ANNOUNCEMENT
Select the signal type.
IMPORTANT: When you select DIAL TONE, you can combine origins (numbers 1 and
2) in the menu. However, when you select ANNOUNCEMENT, you only
have one origin ANNOUNCEMENT FROM. In this latter case, this new
selection appears on screen.
ORIGIN NUMBER 1
TONE 330 HZ TONE 440 HZ HIGH TONE 440 HZ LOW TONE 440 + 330 HZ
*MUSIC **MUSIC SILENCE
Select origin number 1 or modify the existing origin.
* INTERNAL MUSIC (1 melody)
** EXTERNAL MUSIC on M6504/M6540 IP PBX
PEAK DURATION (UNIT 10 MS)
Number of 10 ms units for defining peak duration.
TROUGH DURATION (UNIT 10 MS)
Number of 10 ms units for defining trough duration.
