ORIGIN NUMBER 2
TONE 330 HZ TONE 440 HZ HIGH TONE 440 HZ LOW TONE 440 + 330 HZ
*MUSIC **MUSIC UNDEFINED SILENCE
Select origin number 2 or modify the existing origin.
* INTERNAL MUSIC (1 melody)
** EXTERNAL MUSIC on M6504/M6540 IP PBX
PEAK DURATION (UNIT 10 MS)
Number of 10 ms units for defining peak duration.
TROUGH DURATION (UNIT 10 MS)
Number of 10 ms units for defining peak duration.
ANNOUNCEMENT FROM
The origin of the announcement. This field presents different options depending on the
PBX family (M6501L/R IP or M6504/M6540 IP or XL/XS/XC).
♦ M6501L/R IP PBX
MUSIC EXT. ANALOGUE ROM MESSAGE VOCT3 RAM
MESSAGE
CC1/BVF
♦ M6504/M6540 IP PBX
INTERNAL MUSIC EXT. ANALOGUE VOCH ROM MESSAGE
VOCH RAM MESSAGE CCS
Note: INTERNAL MUSIC corresponds to one of 8 melodies on the VOCH card
(M6504/M6540 IP PBX).
♦ XL/XS/XC
EXTERNAL MUSIC ANALOG EXTENS. FVS-BVF
SLOT/CARD/EQT OR MESSAGE NUMBER
This line is displayed when ANALOG EXTENS. is selected (M6501 L/R IP PBX and
XL/XS/XC), CC1/BVF (M6501 L/R IP PBX), SVF-MEVO (XL, XS, XC) or CCS
(M6504/M6540 IP PBX).
Enter the card/equipment number to be connected or the message number (from 1 to 8).
